DUSB Series 12.5mm 5-Pin DIN Rail Bus Terminal (150V Rated Voltage, 3.81mm Pitch)

Applications: The DUSB 12.5-5P terminal is widely used in automation control, power systems, industrial equipment, robotic systems, and other fields requiring efficient and reliable electrical connections. It can withstand long-term high-load operation, ensuring equipment stability and safety.

Advantages:
High rated current and voltage support ensures safe connections in industrial environments.
Compact design and standard 3.81mm pin pitch facilitate efficient connections in tight spaces.
High interference immunity adapts to various complex environments.
Strict contamination and impulse voltage ratings ensure product stability under various extreme conditions.

Features:
Rated Current: Supports up to 8A rated current (parallel contacts), meeting the current carrying requirements of industrial equipment.
Rated Voltage: Rated voltage of 150V, providing stable electrical connection and safe use.
Pollution Degree: Meets Class 3 pollution standards, suitable for applications in harsh environments.
PCB Thickness: Suitable for 4mm thick PCBs, ensuring robust connections and support.
Rated Impulse Voltage: Supports a rated impulse voltage of 2.5kV, enhancing immunity to interference.
Pin Pitch: The pin pitch is 3.81mm, accommodating a wide range of connection needs.
Dimensions: The housing is 19.2mm wide, 36.3mm high, and 37.65mm long, with moderate dimensions for easy installation.
