90mm DIN Rail Electronic Module Housing Enclosure with 96 Connections (Off White, Lock Type PCB Mount, IP20, with Vent)

Applications: The SF-MEX-9000-3 housing is widely used in automation control, industrial electrical equipment, power management systems, and other fields, providing excellent protection and support for equipment, ensuring stability and reliability in various operating environments.

Advantages:
Compatible with standard DIN rail mounting, adaptable to various electronic devices.
IP20 protection rating ensures safety during normal use.
High-quality PA66 material, with excellent flame-retardant properties and durability.
High connection capacity and compact design save space and improve system integration.

Key Features:
Dimensions: 100.8mm width, 91.8mm length, 114.4mm thickness, suitable for compact equipment installation.
PCB Mounting Capacity: Supports PCBs from 1 to 1.8mm thick, ensuring stable installation and support.
Mounting Position and Type: Suitable for vertical (horizontal) DIN rail mounting with a locking function to ensure secure installation.
Protection Rating: IP20 protection rating, effectively resisting the intrusion of dust and other solid substances, suitable for general industrial environments.
Connection Count and Spacing: Supports up to 96 connections (connection spacing of 5mm), providing excellent electrical connectivity.
Material and Color: Made of PA66 material, possessing excellent flame-retardant properties, meeting UL94-V0 standards, with a beige housing.
Ventilation Design: Equipped with ventilation openings to aid in heat dissipation and ensure stable operation over extended periods.
Temperature Range: Suitable for ambient temperatures from -5°C to 85°C, maintaining high performance during storage and transportation.
