40P Connections 26mm DIN Rail SF-MIL Connector I/O Module Housing

Applications：
Industrial control systems
Building automation (HVAC, lighting control)
PLC and distributed I/O modules
Factory equipment wiring
Electrical junction boxes

Key Features & Benefits：
Optimized Size:​ With dimensions of 26mm (Width) x 75mm (Length) x 104.55mm (Height), the SF-MIL housing saves valuable space in control cabinets while providing ample room for wiring and components.
High Capacity:​ Supports a maximum of 40 connections, making it suitable for complex I/O applications requiring multiple terminals.
Easy Installation:​ Equipped with a Lock-type PCB installation​ system for quick and secure mounting of printed circuit boards.
DIN Rail Compatibility:​ Designed for both vertical and horizontal DIN rail​ mounting, offering flexibility for various installation environments.
Ventilation Design:​ Includes ventilation ports​ to ensure proper heat dissipation, enhancing the performance and lifespan of internal electronics.
Safety First:​ Features IP20 ingress protection, safeguarding against finger contact and solid foreign objects, while the flame-retardant PC material​ ensures safety under high-temperature conditions.
Wide Temperature Range:​ Operates reliably in ambient temperatures from -25°C to +60°C, with storage and transportation capabilities from -40°C to +85°C.
Standard PCB Support:​ Accommodates 1mm PCB board thickness​ and comes with integrated PCB supports for structural stability.
